Specs
Brand | Dorian Tool |
Manufacturer's Part Number | 73310169342 |
Insert Style | WNMG |
Insert Size | 322 |
Material | Carbide |
Inscribed Circle (Decimal Inch) | 0.3750 |
Inscribed Circle (Inch) | 3/8" |
Thickness (Decimal Inch) | 0.1875 |
Thickness (Inch) | 3/16" |
Corner Radius (Decimal Inch) | 0.0313 |
Corner Radius (Inch) | 1/32" |
Manufacturer's Grade | DPC15HT |
Coating | Al2O3/TiCN/Al2O3/TiCN |
Material Grade | C6/C7 |
Chip Breaker | PEM |
Insert Length (Decimal Inch) | 0.2697 |
Hole Diameter (Decimal Inch) | 0.1500 |
Hole Diameter (mm) | 3.81 |
ISO Number | WNMG-060408-PEM-DPC15HT |
Rake | Negative |
Relief Angle | 0 |
Coating Process | CVD |
Manufacturers Catalog Number | WNMG-332-PEM-DPC15HT |
Included Angle | 80 |
Cutting Direction | Neutral |
Maximum Depth of Cut (Decimal Inch) | 0.0390 |
Maximum Depth of Cut (mm) | 0.99 |
Insert Holding Method | Pin & Clamp |
Cutting Edge Style | Honed |
MultiUseTool | No |
Shape | Trigon |
