Specs
| Brand | Dorian Tool | |
| Manufacturer's Part Number | 73310150903 | |
| Toolholder Style | MTJN | |
| Hand of Holder | Left Hand | |
| Rake | Negative | |
| Rake Angle | -7 | |
| Insert Compatibility | TNM 432 | |
| Overall Length (Decimal Inch) | 6.0000 | |
| Shank Width (Inch) | 1 | |
| Shank Width (Decimal Inch) | 1.0000 | |
| Shank Height | 1 | |
| Multi-Use Tool | No | |
| Insert Holding Method | Pin & Clamp | |
| Lead Angle | 3 | |
| Back of Bar to Cutting Edge (Decimal Inch) |
|
|
| Head Length (Decimal Inch) | 1.2500 |
|
| Insert Inscribed Circle (Inch) | 1/2 | |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
