Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
First choice for stainless steels and high temp alloys. Also use on non-ferrous materials except aluminum. Second choice for carbon and alloy steels, and cast iron. Most universal and general purpose grade for multi-material applications.
Specs
| Brand | Dorian Tool |
| Manufacturer's Part Number | 73310172530 |
| Insert Style | TNMA |
| Insert Size | 32 |
| Material | Carbide |
| Thread Type | Internal/External |
| Cutting Direction | Neutral |
| Thread Standard | 60 V |
| Manufacturer's Grade | DASK25B |
| Internal Threads Per Inch | 8.0-36.0 |
| Inscribed Circle (Inch) | 3/8" |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Thickness (Decimal Inch) | 0.1250 |
| Coating | TiAlN |
| Hole Diameter (Decimal Inch) | 0.1500 |
| Hole Diameter (mm) | 3.81 |
| Rake | Negative |
| Rake Angle | 0 |
| Coating Process | PVD |
| Manufacturers Catalog Number | TNMA-32NV-DASK25B |
| Maximum Corner Radius (Decimal Inch) | 0.0050 |
| Corner Radius (Decimal Inch) | 0.0030 |
| Hole Shape | Cylindrical |
