Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Specs
Brand | Dorian Tool |
Manufacturer's Part Number | 73310169321 |
Insert Style | SNMG |
Insert Size | 542 |
Material | Carbide |
Inscribed Circle (Decimal Inch) | 0.6250 |
Inscribed Circle (Inch) | 5/8" |
Thickness (Decimal Inch) | 0.2500 |
Thickness (Inch) | 1/4" |
Corner Radius (Decimal Inch) | 0.0313 |
Corner Radius (Inch) | 1/32" |
Manufacturer's Grade | DPC35RT |
Coating | Al2O3/TiCN/Al2O3/TiCN |
Material Grade | C5 |
Chip Breaker | PEM |
Insert Length (Decimal Inch) | 0.6252 |
Hole Diameter (Decimal Inch) | 0.2500 |
Hole Diameter (mm) | 6.35 |
ISO Number | SNMG-150608-PEM-DPC35RT |
Rake | Negative |
Relief Angle | 0 |
Coating Process | CVD |
Manufacturers Catalog Number | SNMG-542-PEM-DPC35RT |
Included Angle | 90 |
Cutting Direction | Neutral |
Maximum Depth of Cut (Decimal Inch) | 0.3940 |
Maximum Depth of Cut (mm) | 10.01 |
Insert Holding Method | Pin & Clamp |
Cutting Edge Style | Honed |
MultiUseTool | No |
Shape | Square |
