Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Specs
| Brand | Dorian Tool |
| Manufacturer's Part Number | 73310171623 |
| Insert Style | TPG |
| Insert Size | 322 |
| Material | Carbide |
| Corner Radius (Decimal Inch) | 0.3750" |
| Corner Radius (Inch) | 3/8" |
| Thickness (Inch) | 1/8" |
| Thickness (Decimal Inch) | 0.0313" |
| Insert Length (Decimal Inch) | 0.6496" |
| Hole Diameter (mm) | 4.52 |
| Hole Diameter (Decimal Inch) | 0.1780" |
| Maximum Depth of Cut (mm) | 6.10 |
| Maximum Depth of Cut (Decimal Inch) | 0.2400" |
| Manufacturer's Grade | DNU25GT |
| Chip Breaker | UEN |
| ISO Number | TPG-160308-UEN-DNU25GT |
| Rake | Positivo |
| Relief Angle | 11 |
| Manufacturers Catalog Number | TPG-322-UEN-DNU25GT |
| Included Angle | 60 |
| Cutting Direction | Neutral |
| Shape | Triangular |
