Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Specs
| Brand | Dorian Tool |
| Manufacturer's Part Number | 73310171620 |
| Insert Style | TEPG/TPG |
| Insert Size | 431 |
| Material | Carbide |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Inscribed Circle (Inch) | 3/8" |
| Thickness (Inch) | 3/16" |
| Thickness (Decimal Inch) | 0.1875 |
| Corner Radius (Inch) | 1/34" |
| Corner Radius (Decimal Inch) | 0.0156 |
| Hole Diameter (mm) | 4.52 |
| Hole Diameter (Decimal Inch) | 0.1780 |
| Maximum Depth of Cut (mm) | 6.10 |
| Maximum Depth of Cut (Decimal Inch) | 0.2400 |
| Manufacturer's Grade | DPP30GT |
| Chip Breaker | UEN |
| ISO Number | TPG-160304-UEN-DPP30GT |
| Rake Angle | 7 |
| Coating Process | PVD |
| Manufacturers Catalog Number | TPG-321-UEN-DPP30GT |
| Included Angle | 60 |
| Cutting Direction | Neutral |
| Shape | Triangle |
