Specs
| Brand | Dorian Tool |
| Manufacturer's Part Number | 73310158150 |
| Thread Type | External |
| Hand of Holder | Right Hand |
| Toolholder Style | MTVO-A |
| Series | On Edge Jet-Stream |
| A - Shank Width/Diameter (mm) | 31.75 |
| A - Shank Width/Diameter (Decimal Inch) | 1.2500 |
| A - Shank Width/Diameter (Inch) | 1-1/4" |
| B - Shank Height | 1-1/4" |
| B - Shank Height (Decimal Inch) | 1.2500 |
| C - Overall Length (Inch) | 6" |
| C - Overall Length (mm) | 152.40 |
| E (Decimal Inch) | 1.250 |
| F (Decimal Inch) | 1.500 |
| G (Decimal Inch) | 0.250 |
| Insert Compatibility | TNMA-432 |
| Lock Pin | NL-44 |
| Clamp | CL-6 |
| Clamp Screw | XNS-36 |
| Through Coolant | No |
| Multi-Use Tool | Yes |
| Insert Holding Method | Pin & Clamp |
| Maximum Depth of Cut (Decimal Inch) | 0.2300 |
| Head Length (Decimal Inch) | 1.2500 |
| Shank Length (Decimal Inch) | 4.7500 |
| Insert Inscribed Circle (Inch) | 1/2 |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
