Specs
| Brand | Dorian Tool |
| Manufacturer's Part Number | 73310158142 |
| Thread Type | External |
| Hand of Holder | Right Hand |
| Toolholder Style | MTVO-A |
| Series | On Edge Jet-Stream |
| A- Shank Width/Diameter (mm) | 19.05 |
| A - Shank Width/Diameter (Decimal Inch) | 0.7500 |
| A - Shank Width/Diameter (Inch) | 3/4" |
| B - Shank Height | 3/4" |
| B - Shank Height (Inch) | 0.7500 |
| C - Overall Length (Decimal Inch) | 4.5000 |
| C - Overall Length (mm) | 114.30 |
| E | 1.250 |
| F | 0.875 |
| G | 0.250 |
| Insert Compatibility | TNMA-432 |
| Lock Pin | NL-44 |
| Clamp | CL-6 |
| Clamp Screw | XNS-36 |
| Through Coolant | No |
| Multi-Use Tool | Yes |
| Insert Holding Method | Pin & Clamp |
| Back of Bar to Cutting Edge (Decimal Inch) |
1.3750 |
| Maximum Depth of Cut (Decimal Inch) | 0.2300 |
| Head Length (Decimal Inch) | 1.2500 |
| Shank Length (Decimal Inch | 3.2500 |
| Insert Inscribed Circle (Inch) | 1/2 |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
